MAHLE Clevite Connecting Rod Bearings, Chevy/GMC (2001-16) 6.6L Duramax, (0.25mm under)
CB-1805P-.25mm
Material: TM-77
Min. Std. Shaft Diameter: 2.4764" (62.9006mm)
Max. Std. Shaft Diameter: 2.4772" (62.9209mm)
Min. Vert. Oil Clearance: 0.0010" (0.0254mm)
Max. Vert. Oil Clearance: 0.0034" (0.0864mm)
Max. Wall: 0.0795" (2.0193mm)
Min. Brg. O.D. or Housing Bore: 2.6372" (66.9849mm)
Max. Brg. O.D. or Housing Bore: 2.6378" (67.0001mm)
Max. Length: 0.9340" (23.7236mm)
(sizes above do not reflect under sizing)
***Undersize Bearings can be used but the Crankshaft must
be Rehardened with a Nitride Heat Treatment
Min. Std. Shaft Diameter: 2.4764" (62.9006mm)
Max. Std. Shaft Diameter: 2.4772" (62.9209mm)
Min. Vert. Oil Clearance: 0.0010" (0.0254mm)
Max. Vert. Oil Clearance: 0.0034" (0.0864mm)
Max. Wall: 0.0795" (2.0193mm)
Min. Brg. O.D. or Housing Bore: 2.6372" (66.9849mm)
Max. Brg. O.D. or Housing Bore: 2.6378" (67.0001mm)
Max. Length: 0.9340" (23.7236mm)
(sizes above do not reflect under sizing)
***Undersize Bearings can be used but the Crankshaft must
be Rehardened with a Nitride Heat Treatment
Was:
$13.48
Sale:
$12.84
Save:
5%
Save:
$0.64
Quantity Pricing
Purchase 8:
$10.87 ea.
Description
Cross Reference Part Numbers:
General Motors: 97250338
General Motors: 97250410
SEALED POWER: 8-4995P
General Motors: 97250338
General Motors: 97250410
SEALED POWER: 8-4995P
Details
- CB-1805P-.25mm
- CB-1805P-.25mm
- 027067379672
- Mahle
- New
Shipping Information
- Item Requires Shipping
- 0.2 lbs.
- W2.2500” x H1.2500” x L3.1870”
