Revolution Gear & Axle Ring & Pinion Set for Chrysler 9.25" Rear Axle (4.56 Ratio, Dual Drilled)

This Revolution Gear & Axle ring and pinion set fits the Chrysler 9.25" rear axle used from 1970-2018, cut in a 4.56 ratio. The dual-drilled ring gear carries two bolt patterns so a single part covers both earlier and later 9.25" carriers.

The gears use a 29-spline pinion, a 9.25" ring gear, dual ring gear bolt threads for the two bolt patterns, and heat-treated 8620 steel, in standard rotation. There is no carrier break on this gear family, so a 4.56 works without changing carriers.

A 4.56 ratio is a deeper gear aimed at Dodge and Chrysler trucks running larger tires that need to recover acceleration, towing torque, and drivability lost to the taller rubber. It puts the engine back in a usable RPM range for both daily driving and pulling.

This is a gear set only. It does not include bearings, shims, a crush sleeve, a pinion seal, or a locker – those are sold separately. The dual-drilled design eases fitment across 9.25" applications, but still confirm your axle and carrier before ordering. Professional gear setup is recommended.

Pair this set with a Revolution Chrysler 9.25" master install kit for a quiet, durable rebuild backed by a 2-year warranty against manufacturing defects.
