Revolution Gear & Axle Ring & Pinion Set for Ford 8.8" Rear Axle (3.55 Ratio)

This Revolution Gear and Axle ring and pinion set is a 3.55 ratio gear for the Ford 8.8 inch rear axle, one of the most widely used Ford rear ends across trucks, SUVs and cars. It is a sensible ratio for street and light-tow use.

The set features a 30-spline pinion, an 8.8 inch ring gear and standard rotation, with no carrier break to work around and the factory 10 x 7/16 inch ring gear bolt pattern. Gears are 8620 steel, heat treated to OE-level standards and lapped for quiet running.

A 3.55 ratio keeps highway RPM low while adding a little more pep than the tallest factory ratios, making it a good fit for stock-height trucks or mild builds that still see plenty of pavement.

This is a gear set only. It does not include bearings, an install kit or a limited slip/locker. Plan on the matching Revolution Ford 8.8 master install kit for your spline count and have an experienced installer set pinion depth, backlash and preload to spec.

For an 8.8 that needs fresh, quiet gears, a 3.55 ring and pinion is an OE-quality replacement that holds up to daily use.
