Industrial Injection Garrett Intercooler Upgrade for Ford (2015-25) F-150 & Raptor 3.5L/2.7L EcoBoost
870702-6001
Industrial Injection Garrett Intercooler Upgrade for Ford F-150 & Raptor 3.5L/2.7L EcoBoost
Garrett Performance Charge Air Cooler for 2015+ Ford F-150 & Raptor (3.5L & 2.7L EcoBoost) – C.A.R.B. Certified, Supports Up to 750 HP
Replace Heat with Horsepower.
Engineered for 2015 and newer Ford F-150 and F-150 Raptor models with 3.5L and 2.7L EcoBoost engines, the Garrett® Direct Fit Performance Charge Air Cooler is the ultimate bolt-on intercooler upgrade. With an 83% larger aluminum core, this intercooler delivers up to a 30°F drop in charge air temperatures and a 30% reduction in pressure drop versus stock—helping your engine breathe cooler, denser air for more consistent power under demanding conditions.
Dyno-tested for proven performance gains, this upgraded intercooler supports up to 750 horsepower while maintaining emissions compliance with C.A.R.B. EO# D-794, making it 50-state legal.
Garrett Performance Charge Air Cooler for 2015+ Ford F-150 & Raptor (3.5L & 2.7L EcoBoost) – C.A.R.B. Certified, Supports Up to 750 HP
Replace Heat with Horsepower.
Engineered for 2015 and newer Ford F-150 and F-150 Raptor models with 3.5L and 2.7L EcoBoost engines, the Garrett® Direct Fit Performance Charge Air Cooler is the ultimate bolt-on intercooler upgrade. With an 83% larger aluminum core, this intercooler delivers up to a 30°F drop in charge air temperatures and a 30% reduction in pressure drop versus stock—helping your engine breathe cooler, denser air for more consistent power under demanding conditions.
Dyno-tested for proven performance gains, this upgraded intercooler supports up to 750 horsepower while maintaining emissions compliance with C.A.R.B. EO# D-794, making it 50-state legal.
Was:
$1,290.99
Sale:
$1,074.99
Save:
17%
Save:
$216.00
Description
Features:
•83% Larger Core than OEM for superior cooling
•+16 HP Gain at heat saturation (dyno proven)
•Up to 30°F Lower Intake Air Temps
•Up to 30% Less Pressure Drop
•Cast Aluminum End Tanks for durability and improved airflow
•Bar-and-Plate Design with offset fins for optimal heat dissipation
•C.A.R.B. Certified (EO# D-794) for emissions compliance
•Fully TIG Welded and vacuum brazed
•Quick Installation – installs in under 2 hours using factory hardware
•Direct-Fit for 2015–2020+ Ford F-150 & Raptor EcoBoost models
???? Bonus Feature – Integrated Drain Plug
Condensation is a known issue on the F-150 EcoBoost platform. Garrett addresses this with a fully machined drain plug to easily remove moisture buildup. Simply remove the bolt with a 3/8" wrench, catch any fluid, and rev the engine gently to clear any residuals.
???? Intercooler Specs:
Core Dimensions: 21" x 5.32" x 9.43"
Application: 2015+ Ford F-150 & Raptor (2.7L / 3.5L EcoBoost)
Part Number: 870702-6001
⚠️ Notes:
Will not fit other vehicle applications.
Grille shutters must be removed to install this product.
•83% Larger Core than OEM for superior cooling
•+16 HP Gain at heat saturation (dyno proven)
•Up to 30°F Lower Intake Air Temps
•Up to 30% Less Pressure Drop
•Cast Aluminum End Tanks for durability and improved airflow
•Bar-and-Plate Design with offset fins for optimal heat dissipation
•C.A.R.B. Certified (EO# D-794) for emissions compliance
•Fully TIG Welded and vacuum brazed
•Quick Installation – installs in under 2 hours using factory hardware
•Direct-Fit for 2015–2020+ Ford F-150 & Raptor EcoBoost models
???? Bonus Feature – Integrated Drain Plug
Condensation is a known issue on the F-150 EcoBoost platform. Garrett addresses this with a fully machined drain plug to easily remove moisture buildup. Simply remove the bolt with a 3/8" wrench, catch any fluid, and rev the engine gently to clear any residuals.
???? Intercooler Specs:
Core Dimensions: 21" x 5.32" x 9.43"
Application: 2015+ Ford F-150 & Raptor (2.7L / 3.5L EcoBoost)
Part Number: 870702-6001
⚠️ Notes:
Will not fit other vehicle applications.
Grille shutters must be removed to install this product.
