KT Performance - Digital Screen Gauges

Display Features:

7.0” TFT LCD panel, 1000 nit brightness for unmatched daytime and nighttime visibility with 800x480 resolution. Onboard photo sensor for automatic brightness control
Dimensions - 8.3" Wide x 5.2" High x 1.4" Deep
Carbon Composite Housing
Single 37 way autosport (AS) wiring loom connector for ease of installation and removal
12 analog inputs for discrete sensors ideal for parameters not supported on the vehicle communication bus or ECU. Expansion modules available separately for additional input
DataPro Designer PC Setup utility
Fully user configurable from display via integrated 4 button interface for at track changes. Optional external switch set can be mounted within driver reach for easy access
16 configurable multi-color LED indicator lights can be programmed for a wide variety of alarm and shift / gear change indication functions
Initial release supports 6 layers or screens selected from user- configurable templates (screens/instrument cluster designs/layouts), additional configurability supporting team selected graphics, parameter/instrument type and location, and size will be made available with future firmware and PC software releases
Display features perfectly rendered virtual analog needles, value display bands, digital value indicators for vehicle parameters and configurable full color text warning messages
Patented Predictive Lap Timing Display for Driver and Vehicle Development

Inputs:
4 pulse/digital or analog inputs (0-5V, Hz, or resistive)
8 analog inputs (0-5V)
5 external switches / control outputs
Internal 3-axis accelerometer +/-6g
Internal battery voltage
GPS Mapping and Lap Timing

Communications:

2 Configurable RS232 ports
Configurable CAN BUS ports
Ethernet port for PC comms:(config. & firmware upgrades)
1 USB port: data exchange, configuration,copy/upload, & firmware updates.

Data Recording:

4 GB Onboard Datalogging Memory
Record up to 128 channels
Sample rates up to 500 Hz (Select inputs 1000 Hz)
Includes powerful DataPro Analysis Software

Environmental:

IP65 sealed
Operating temperature range: 20ºF to 180ºF
Humidity: 0-100% RH
Continuous vibration up to 20g, Shock up to 50g

The Included EAS Starter Kit only works with the CS and CTS product lines. In order to use the EAS accessories you must have an EAS Starter kit. EAS Starter kits also come with all Juice w/ Attitude CS and CTS products.

EAS Starter Kit is not included. In order to use the EAS accessories you must have an EAS Starter kit (part # 98602). EAS Starter kits come with all Juice w/ Attitude CS and CTS products and the EAS EGT Probe for CS & CTS, Expandable with Starter Kit (part # 98603).

Tolerance: +-1.5% Full Span over temperature range of -20C to 85C and +-2.4% Full Span over temperature range of -40C to 135C.

EAS Starter Kits are only available to work with the CS and CTS product lines. In order to use the EAS accessories you must have an EAS Starter kit (part # 98602). EAS Starter kits come with all Juice w/ Attitude CS and CTS products and the EAS Starter Kit w/ Expandable EGT (part # 98603).

****Turbo timers are only available to work with the CS and CTS product lines. In order to use the turbo timer you must have an EAS Starter kit (part # 98602). EAS Starter kits come with all Juice w/ Attitude CS and CTS products and the EAS Starter Kit w/ Expandable EGT (part # 98603).

This part is legal under the provisions of EPA’s memorandum 1A. The company has reasonable basis (test results) to verify that this product allows the vehicle to operate within legal emissions standards and is therefore legal to be sold for on-street use in all states that accept the legal provisions of the Clean Air Act and EPA Memorandum 1A. This product is NOT LEGAL FOR SALE OR USE IN THE STATE OF CALIFORNIA. Testing with the California Air Resources Board, in order to achieve 50-state compliance, is pending with CARB. Once testing is complete with California, and an E.O. number is issued, this product will be updated to 50-state legal status

This part is legal under the provisions of EPA’s memorandum 1A. The company has reasonable basis (test results) to verify that this product allows the vehicle to operate within legal emissions standards and is therefore legal to be sold for on-street use in all states that accept the legal provisions of the Clean Air Act and EPA Memorandum 1A. This product is NOT LEGAL FOR SALE OR USE IN THE STATE OF CALIFORNIA. Testing with the California Air Resources Board, in order to achieve 50-state compliance, is pending with CARB. Once testing is complete with California, and an E.O. number is issued, this product will be updated to 50-state legal status

This part is legal under the provisions of EPA’s memorandum 1A. The company has reasonable basis (test results) to verify that this product allows the vehicle to operate within legal emissions standards and is therefore legal to be sold for on-street use in all states that accept the legal provisions of the Clean Air Act and EPA Memorandum 1A. This product is NOT LEGAL FOR SALE OR USE IN THE STATE OF CALIFORNIA. Testing with the California Air Resources Board, in order to achieve 50-state compliance, is pending with CARB. Once testing is complete with California, and an E.O. number is issued, this product will be updated to 50-state legal status

Insight CTS2 Features:
•Slim, sleek case design
•5” full–color, high-resolution, swipe screen
•Custom color mixer for gauge arcs, needles, and backgrounds
•Multiple gauge screen layouts
•Fully customizable backgrounds
•HDMI style plug for power and linking EAS accessories
•One-touch easy menu navigation
•Notification center
•Available for 1996 and vehicles equipped with an OBDII (diagnostic) port
•Switch between US or Metric units of measure
•Comprehensive digital gauge display
•Available for 1996 and newer vehicles equipped with an OBDII port
•Compatible with other tuning devices
•Displays dozens of parameters
•Light sensitivity meter to dim screen as ambient light decreases
•Internet Updateable

*Some features may vary by make/model/year. Add your vehicle to search for parts and features specifically for your application.

Exclusive Technology Not Available Anywhere Else!

Edge has raised the bar again with the innovative features in the CTS3 screen that are not found in similar tuners/monitors

-Razor thin display integrates into your cab seamlessly unlike other bulky monitors and busy gauge clusters.
-5” HD screen, the largest available on the market, accommodates up to multiple colors and clocks at a faster frame rate
than competing monitors.
-Proprietary one-touch navigation menu. Seamlessly swipe through data and check alerts with the most intuitive and improved
user interface ever designed for a truck programmer/monitor
-One HDMI cable to power the monitor and link your EAS accessories as opposed to multiple inputs and bulkier cables that
come standard on other devices.
-Day or night with Edge’s built in light sensitivity meter your monitor will adjust the brightness giving you the ideal
brightness while driving.


Take Performance to the Next Level!

Edge has been and still is the king of truck performance and monitoring. We increase the maximum exposure of your engine while simultaneously monitoring parameters for alerts to improve your overall driving experience.



-Multiple shift-on-the-fly performance tuning settings with EAS and serial to control power and control for any situation.
Log, graph, and export hundreds of parameter to track or improve performance
-Test and track performance runs such as 0-60mph, and ¼ mile



Customize it and Make it Your Own!

Everyone’s needs are different. Whether you are using your truck for work, pleasure, or competition – no other vehicle monitoring system gives you more customization options than Edge!



-Display hundreds of different combinations of gauges in digital or analog format in Metric or US units
-Set audible & visual alert notifications when certain parameters or temperatures are met
-Adjust the background screen, gauge arcs, keylines, and needles to virtually any color to make it your own or match your
vehicle’s interior.
-EAS (Expandable Accessory System) compatible. Add additional sensors, probes, and switches and monitor them on the screen!
-Add safety by installing a backup camera. CTS3 contains a USB port and accommodates the simple install of Edge’s Backup
camera.
-Your factory speedometer is no longer accurate once you add larger tires. Easily add your new tire size and display your
true speed through your CTS3 Monitor.
-Ships with state-of-the-art suction cup and ability to work with Edge’s custom mounting solutions for that factory
installed look.
-WiFi and Internet updatable to stay up with future feature releases never missing out on the next big thing.

Insight Pro CTS2 Features:
• Insight Pro will act the same as a normal Insight
• Ability To Read Stock File
• Cloud Based Consumer downloads directly to Insight Pro
• Cloud Based Dealer Portal
• Dealers Can Name Each Tune
• Store Up To 4 Custom Tunes
• Gas and Diesel Applications Supported
• Displays Dozens of Parameters
• Multiple Screen Layouts
• Data Logging
• EAS Compatible for Additional Accessories
• Performance Testing and Diagnostics
• Slim, sleek case design
• 5” full–color, high-resolution, swipe screen
• Custom color mixer for gauge arcs, needles, and backgrounds
• Fully customizable backgrounds
• HDMI style plug for power and linking EAS accessories
• One-touch easy menu navigation
• Notification center
• Switch between US or Metric units of measure
• Light sensitivity meter to dim screen as ambient light decreases
• Internet Updateable


*Some features may vary by make/model/year. Add your vehicle to search for parts and features specifically for your application.

From the factory, your vehicle's computer is calibrated for the masses, designed with the average driver in mind, not the performance enthusiast. This not only leaves valuable Horsepower & Torque hidden inside your vehicle, but it also makes for a mediocre driving experience. The iTSX / TSX for Apple / Android System unlocks your vehicle's hidden performance potential by wirelessly re-calibrating your vehicle's computer for Maximum Horsepower & Torque, Increased Throttle Response, Firmer Shifts and even Increased Fuel Mileage.

The iTSX / TSX for Apple / Android App lets you control the vehicle-tuning and monitoring capabilities of the iTSX / TSX for Apple / Android App Wireless OBD-II Interface. The iTSX / TSX for Apple / Android App Wireless OBD-II Interface plugs into your vehicle's OBD-II diagnostic connector, and communicates with your Apple or Android device via a secure Bluetooth wireless connection.

Built-In Performance Tests & Data Monitoring:
- 0-60MPH Performance Test with Estimated HP & TQ
- On-Screen Virtual Gauges with Adjustable Warning lights
- ET / MPH Performance Test with 1/8th & 1/4 mile
- Monitor Vehicle Engine Data via Virtual Gauges
- Top Speed Performance Test
- Huge Virtual Gauges on Tablets ( 9.5" wide X 7.4" tall )
- Braking Performance Test with 60-0MPH ET
- Selectable Gauge Themes & Layouts

Color 4" Touch Screen Display
-Livewire TS features a full color 4" touch screen display with built-in ambient light sensor for automatic brightness adjustment day & night.

Automatic On / Off / Sleep Mode
- Tired of devices that stay on after the ignition is turned off? Livewire TS features both a Sleep & Auto Off mode. 2 minutes after the ignition is turned off, Livewire TS goes into sleep mode, drawing very little power. After 2 days of inactivity, it automatically turns itself off to save your vehicle's battery.

Reads & Clears DTC Codes
- Reads and clears diagnostic trouble codes quickly & easily, saving on expensive diagnostic fees.

High Speed Data Logging & Monitoring
- Need to monitor your vehicle's engine parameters? No need for a separate monitoring device. View & record your vehicle's PCM data on the Livewire TS.

User Selectable Graphics & Gauge Layouts
- Customize the look of your Livewire TS with user selectable themes, colors and gauge layouts.

User Adjustable Warning / Alerts
- Easy to configure gauge warning & alerts for critical engine parameters.

Rear View Camera Input
- The Rear View Camera Input Connector is built-in to the Livewire TS OBD-II Cable for easy connection of most aftermarket Rear View Cameras!

Holds up to 10 Custom Tunes
- The Livewire TS arrives Pre-Loaded with performance tune files & holds up to 10 custom tuning files for Maximum tune flexibility.

Built-In Performance Calculator
- 0-60MPH Performance Test with Estimated HP & TQ
- ET / MPH Performance Test with 1/8th & 1/4 mile
- Top Speed Performance Test
- Braking Performance Test with 60-0MPH ET

User Adjustable Tune Options
- Adjust for common performance bolt-ons such as Cold Air Kits, Exhaust Systems & Gears.

Available for both Gas & Diesel Vehicles

Windshield Mount Included
- No mounting solution required. Livewire TS includes a suction cup style mount for easy mounting on your vehicle's windshield.

The X4 Power Flash device backs up your factory PCM program during installation should you ever need to return your vehicle to the stock PCM program. Restoring your vehicle to the stock PCM program is as easy as selecting Return to Stock from the device menu.

X4 Ford Product Features:
-Increases Horsepower & Torque!
-Stores 10 Custom Tunes
-Full Color Backlit LCD Display
-High Speed Datalogging / Monitoring
-Reads/Clears DTC Trouble Codes
-Easy Restoration Back to Stock
-Dual Analog Inputs
-Most Popular Vehicles Supported
-Installs Quickly & Easily
-USB Interface Cable Included
-User Adjustable Vehicle Parameters
-Built-In Wifi for easy updates

•Slim, Sleek Case Design
•5” Full–Color, High-Resolution, Swipe Screen
•Custom Color Mixer for Gauge Arcs, Needles, and Backgrounds
•Multiple Gauge Screen Layouts
•New switch panel screen to control EAS Power Switches
•Fully Customizable Backgrounds
•HDMI Style Plug for Power and Linking EAS Accessories
•One-Touch Easy Menu Navigation Notification Center
