Warn Electric Winch, 16.5ti Thermometric Winch
68801
The 16.5ti features the full diagnostic ability of WARN thermometric technology, plus the extreme sealing, durability, and reliability that the WARN ti-series of winches are known for. Series-wound motor combined with a 3-stage planetary geartrain delivers 16,500 lbs. of pulling power. Thermometric indicator LED provides operator feedback on motor temperature.
-Extreme-duty sealing helps protect the winch from the outside elements
-Series-wound, high-speed motor provides fast line speed and strong pulls
-Exclusive brake design provides superior control while winching
-Aluminum control box cover for added protection of the electronics
-Durable 3-stage planetary geartrain for smooth, reliable, operation
-Remote control with 12' (3.7m) lead and thermometric LED indicator for operator feedback
-Chip-resistant powder-coated finish with primer undercoating for superior corrosion protection
-90' of 7/16" (27m of 11mm) diameter wire rope
-Extreme-duty sealing helps protect the winch from the outside elements
-Series-wound, high-speed motor provides fast line speed and strong pulls
-Exclusive brake design provides superior control while winching
-Aluminum control box cover for added protection of the electronics
-Durable 3-stage planetary geartrain for smooth, reliable, operation
-Remote control with 12' (3.7m) lead and thermometric LED indicator for operator feedback
-Chip-resistant powder-coated finish with primer undercoating for superior corrosion protection
-90' of 7/16" (27m of 11mm) diameter wire rope
Was:
$3,341.17
Sale:
$2,839.99
Save:
15%
Save:
$501.18
Description
Part Number: 68801
Motor: 12V 4.6 hp, Gen II, Series Wound
Electrical Control: Solenoid Control Pack
Remote control: Remote switch, ti, with LED indicator 12 ft (3.7m) lead
Geartrain: 3-stage planetary
Gear ratio: 315:1
Clutch (freespooling): Rotating ring gear
Brake: Automatic direct drive cone
Wire rope: 90 ft, 7/16 in diameter (27m, 11mm diam.)
Fairlead: Roller
Recommended battery: 650 CCA minimum for winching
Battery leads: 2 gauge, 72 ft (1.83m)
Finish: High-gloss powder coat over primer undercoating
Drum diameter/length: 3.5 in /8.2 in (9cm/21cm)
Weight: 138 lbs. (63 kgs.)
Winch Dimensions: 24.2" L. x 8.5" D. x 9.7" H.
(628mm L. x 216mm D. x 247mm H.)
Mounting Bolt Pattern: 10.0" x 4.5" (254mm x 114.3mm)
Motor: 12V 4.6 hp, Gen II, Series Wound
Electrical Control: Solenoid Control Pack
Remote control: Remote switch, ti, with LED indicator 12 ft (3.7m) lead
Geartrain: 3-stage planetary
Gear ratio: 315:1
Clutch (freespooling): Rotating ring gear
Brake: Automatic direct drive cone
Wire rope: 90 ft, 7/16 in diameter (27m, 11mm diam.)
Fairlead: Roller
Recommended battery: 650 CCA minimum for winching
Battery leads: 2 gauge, 72 ft (1.83m)
Finish: High-gloss powder coat over primer undercoating
Drum diameter/length: 3.5 in /8.2 in (9cm/21cm)
Weight: 138 lbs. (63 kgs.)
Winch Dimensions: 24.2" L. x 8.5" D. x 9.7" H.
(628mm L. x 216mm D. x 247mm H.)
Mounting Bolt Pattern: 10.0" x 4.5" (254mm x 114.3mm)
