MaxTow White Double Vision Boost Pressure Gauge, 35psi

MT-WDV01_35
MaxTow’s White Double Vision Series 35 PSI Boost Gauge is an electronically driven diesel truck gauge that includes an electronic boost sensor which reads and displays your truck’s boost pressure levels from 0 to 35 PSI with unmatched accuracy, while eliminating the need of running a lengthy vacuum hose and t-fitting.

MaxTow’s White Double Vision Gauge Series features a green LED display and an illuminated red needle, which gives you the classic look of an analog gauge, as well as an easy to read green digital numerical readout. The Double Vision Gauge Series offers multiple options and added convenience when reading the output of your truck gauge! This 2 1/16 inch (52mm) boost gauge outperforms the competition by featuring stepper motor technology which allows for exceptionally smooth needle movement and extremely precise gauge readings. No matter how much your truck is shaking or pulling, the needle is unaffected and delivers the accurate results you’re looking for. This boost gauge also features innovative daytime and nighttime modes with three customizable brightness settings for each mode. The three daytime brightness settings (d1, d2, d3) allow you to easily view your gauge readings without being affected by the sunlight, while the three nighttime brightness settings (n1, n2, n3) allow up to a 50% more subtle glow for your gauge while driving during the late hours of the night. Also featured with the nighttime mode is that the illuminated red needle will match the brightness level of the gauge for easier viewing at night! The included brightness recall function will remember the previous brightness setting you had on before powering your vehicle down so you won’t have to reset it every time you turn your vehicle on.

Every White MaxTow boost gauge features extended wire harnesses for both power (3ft) and boost pressure sensor (9ft) connections, assuring that you’ll have more than enough wire for a quick and easy installation. All gauge mounting hardware and installation instructions come standard with every diesel boost pressure gauge purchased, as well as a one year limited warranty and free lifetime technical support. Get ready to hit the road and Tow to the Max.


-2 1/16 Inch White Gauge Face with a Magnified Lens
-Gauge Depth Measures 1-5/16"
-Boost Reading from 0 to 35 PSI
-Double Vision Display Feature with Analog and Digital Readings
-Green LED Through Dial Lighting with a Red Illuminated Needle
-Daytime Mode with 3 Customizable Brightness Settings
-Nighttime Mode with 3 Customizable Brightness Settings
-Electronic Boost Pressure Sensor
-9 Foot Boost Pressure Sensor Wire
-6 Feet of Vacuum Hose and T-Fitting
-3 Foot Power Wire
-Mounting Hardware
-Installation Instructions
-Free Lifetime Technical Support
-One Year Limited Warranty


Was: $101.99
Sale: $84.99
Save: 17%
Save: $17.00
Qty:
Free Shipping!

Description

PSI Range of Reading: 0 - 35 PSI
Diameter of Gauge: 2-1/16" or 52mm
Depth of Gauge: 1-5/16" or 33mm
12 Volt Power Required: ✓
Power Wire Harness Length: 3'
Sensor Wire Harness Length: 9'
Power Harness Gauge Size: 18 Gauge
Sensor Thread Size: 1/8" NPT Male Barbed Fitting and 1/8" Inner Diameter T-Fitting
Actual Sensor Size: 2" x 1" x 3/4"
Sensor Wire Included Parts List: Power Harness, Sensor Harness, Boost / Vacuum Sensor, Vacuum Line, Plastic Non Restricted T-Fitting, Inline Filter, Hose Clamp, Mounting Hardware, Gauge Visor and Instructions

Details

  • MT-WDV01_35
  • MT-WDV01_35
  • 604697378550
  • MaxTow Gauges
  • New

Shipping Information

  • Item Requires Shipping
  • 0.8 lbs.
  • W5.0000” x H3.0000” x L7.0000”
  • Free Shipping!
