Warn Electric Winch, Zeon 12 - 12,000lb Winch

89120
The WARN ZEON 12 is the face of winching. Bolt one on, and you'll be ready for anything.

A top choice for those with heavily-loaded off-road vehicles, the ZEON 12 features innovative design, increased performance and durability, steel rope, and a hefty 12,000 lb. single-line pulling capacity.

The ZEON 12 is a pulling machine you can rely on to rescue you or your buddies, from nearly anything.
-12,000 lb. (5443 kg) single-line pulling capacity.
-Includes 80' of durable 3/8" galvanized steel wire rope.
-Gear train and motor deliver reliable pulling power that is fast, and quieter than ever.
-Satin-black powder-coated finish with stainless steel fasteners and clutch lever looks great and inhibits corrosion. Improved winch sealing to keep the elements out.
-Large diameter winch drum reduces rope wear, is light weight, and has an integrated rope anchor for easy rope installation.
-Backed by the WARN Limited Lifetime Warranty.
-Convertible control pack can be attached to the winch or remotely mounted, allowing for various winch mounting options and looks (Relocation kit required and sold separately*).
*Control Pack Relocation Kit. Required to mount control box remotely from winch. PN 89970 (Short kit), PN 89960 (Long kit)

Mounting Bolt Pattern: 10.0" x 4.5" (254mm x 114.3mm)
Was: $1,199.00
Sale: $1,079.99
Save: 10%
Save: $119.01

Customize Your Item

- Choose a size: -
 * required
Qty:
Free Shipping!

Description

ZEON 10 SPECS/PART NUMBER
-Part number: 88990 (12V)
-Rated line pull: 10,000 lbs. (4536 kg) single-line
-Motor: series wound, 12V DC, 24V DC
-Electrical controls: Contactor
-Remote Control: Remote switch, 12' (3.7m) lead
-Geartrain: 3-stage planetary
-Gear ratio: 216:1
-Clutch (freespooling): Rotating ring gear
-Brake: Automatic mechanical cone
-Drum diameter/Length: 3.15"/9.0" (80mm/229mm)
-Weight (kit shipping): 98 lbs. (44 kg)
-Rope: 3/8" x 80' (9.52mm x 24.38m) steel
-Fairlead: Roller
-Recommended Battery: 650 CCA minimum for winching
-Battery leads: 2 gauge, 72" (1.83m)
-Finish: Satin-black powder coat
-Warranty: Limited lifetime


12V DC PERFORMANCE SPECS
Line Pull (Lbs) ..... Line Speed (FT/min) ..... Motor Current
0 ................... 28.1 .................... 66 amps
2000 ................ 14.2 .................... 141 amps
4000 ................ 9.3 ..................... 209 amps
6000 ................ 7.8 ..................... 272 amps
8000 ................ 6.4 ..................... 335 amps
10000 ............... 4.3 ..................... 401 amps
12000 ............... 3.3 ..................... 469 amps

Pull strength by layer (layer/Lbs)
1: 12000
2: 9894
3: 8117
4: 7324

Details

  • 89120
  • 89120
  • 012748896609
  • Warn
  • New

Shipping Information

  • Item Requires Shipping
  • 103.5 lbs.
  • W8.5000” x H19.7500” x L26.2500”
