Torxx Truck Winch Kit 8,000lbs with wire fairlead

W80080
Designed by enthusiasts for enthusiasts. Torxx offers a great line of truck winches with a broad assortment of accessories designed for the off-road and racing enthusiast. Kit includes winch, roller fairlead, battery lead cables, 100' wire rope, and remote control.

Heavy duty steel housing and frame components for maximum strength, durability, and reliability. Premium series wound 5.2hp (3.8kw) motor for maximum performance powers loads in and out. It comes with an automatic load holding brake and it has a freespooling clutch for quick deployment.


Rated Line Pull:
-8,000lbs

Motor:
-12V DC 5.2hp (3.8kW) Series Wound

Control:
-Remote hand held with 12' lead

Gear Train:
-3 stage planetary

Gear Ratio:
-235:1

Clutch:
-Freespooling

Brake:
-Automatic Load Hold

Wire Rope Dia x L:
-5/16" x 100' (8.1mm x 30.48m)

Drum Dia x L:
-2.5" x 8.8" (63.5mm x 223.5mm)

Battery Leads:
-2ga x 6'

Overall Dimensions
-21"L x 6.3"W x 8.6"H (533.4 x 160 x 218.4mm)

Mounting Bolt Pattern:
-10" x 4.5" (254 x 114.3mm)

Weight:
-80lbs (38kgs)

Roller Fairlead:
-Included

2 Year Limited Warranty
Was: $455.73
Sale: $425.34
Save: 7%
Save: $30.39
Qty:
Free Shipping!

Description

Recommended for Maximum Performance:
-650CCA Battery for maximum power
-Snatch block/pulley block to double line for loads over 5000lbs

-----------------------------------
-Pull Speed & Amps
Line Pull lbs...Line Speed ft/min...Current (Amps)
0...........................22..............................80
4000....................12..............................200
6000....................9................................270
8000....................6.5.............................330
-----------------------------------
-Line Pull and Rope Capacity in Layer
Layer...Rated Line Pull (lbs)...Total Rope on Drum (ft)
1.......................8000............................19.6
2.......................6540............................42.6
3.......................5500............................72
4.......................4750............................100
